| Packages | |
| jestr | This package contains the public API to Jestr. |
| jestr.conf.props | Contains classes pertaining to property-file configuration of Jestr. |
| jestr.core | Contains default implementations of the interfaces declcared in the "jestr" package. |
| jestr.examples.example1 | This example illustrates default stringification. |
| jestr.examples.example2 | This example shows how to override an existing toString() method. |
| jestr.examples.example3 | This example illustrates enumeration stringification. |
| jestr.examples.example4 | This example illustrates child filtering. |
| jestr.examples.example5 | This example illustrates more advanced usage of the "standard" predicate. |
| jestr.examples.example6 | This example illustrates initializer classes. |
| jestr.examples.example99 | This is an example covering every feature including some experimental features. |
| jestr.generic.collection | Contains general-purpose Collection-related utilities not specific to Jestr. |
| jestr.generic.exception | Contains general-purpose Exception-related utilities not specific to Jestr. |
| jestr.generic.functor | Contains general-purpose Functor-related utilities not specific to Jestr. |
| jestr.generic.io | Contains general-purpose IO-related utilities not specific to Jestr. |
| jestr.generic.io.core | Contains implementations of interfaces declared in jestr.generic.io. |
| jestr.generic.object | Contains general-purpose Object-related utilities not specific to Jestr. |
| jestr.generic.oro.text.regex | Contains general-purpose ORO-related utilities not specific to Jestr. |
| jestr.generic.reflect | Contains general-purpose Reflection-related utilities not specific to Jestr. |
| jestr.generic.string | Contains general-purpose string-related utilities not specific to Jestr. |
| jestr.generic.type | Contains general-purpose type-related utilities not specific to Jestr. |
| jestr.multiLine | Contains stringifiers for the multiline format, which lists an object's fields or a collection's elements in a manner akin to Java source code listings. |
| jestr.multiLine.collection | Multiline Collection stringifiers. |
| jestr.multiLine.noncollection | Multiline Non-Collection stringifiers. |
| jestr.singleLine | Contains stringifiers for the single-line format, which places all of an object's attributes on one line in a manner suitable for input to text processing tools like awk, sed, and grep. |
| jestr.singleLine.collection | Single-Line Collection stringifiers. |
| jestr.singleLine.noncollection | Single-Line Non-Collection stringifiers. |
| jestr.test | |
| jestr.xml | |
| jestr.xml.collection | XML Collection stringifiers. |
| jestr.xml.noncollection | XML Non-Collection stringifiers. |
| jestr.xml.test | |
Jestr is an extensible, Open Source framework for converting arbitrary Java objects
into strings for display or logging. The style of string conversion can be adjusted at runtime, either
in a blanket fashion or just for individual classes, class hierarchies, and package hierarchies.
Jestr is configurable using a properties file called "jestr.properties", which models
"log4j.properties" and should look reasonably familiar to those accustomed to Log4J.
Below is a partial feature list:
Collection's,
Map's, or array's elements, whether or not source is available for such objects.awk, sed, and grep; and XML. Additional
formats can be added via extension of existing classes.Stringifier,
ChildFilter,
ChildEnumerator,
ChildStringifier,
TSFormat,
TSPreference,
PrettyPrintWriter,
BeforeChildrenHandler,
AfterChildrenHandler,
BetweenChildrenHandler--allowing the framework's behavior to be redefined
at very fundamental levels.
Jestr.str(x) anywhere you are using
x.toString() to create a string representation of object
x for a call to the logger. For instance, assuming we are
using Jakarta Commons Logging, we would just replace this:
Account account = ...;
if ( log.isDebugEnabled() ) {
log.debug( "Here is my account: " + account );
}
with this:
import jestr.*;
// ...
Account account = ...;
if ( log.isDebugEnabled() ) {
log.debug( "Here is my account: " + Jestr.str(account) );
}
or alternatively, you could modify the toString() method of Account to return
Jestr.str(this) and leave the logging statement alone. The two approaches are
functionally equivalent and the choice between them is a matter of style.
If Account is declared as follows:
public class Account {
private double currentBalance = 100.0;
private double endingBalance = 62.44;
private double ledgerBalance = 89.75;
private String currencyCd = "USD";
private String id = "123";
}
then the above logging statement would log the following:
Here is my account: Account(
double currentBalance = 100.0
double endingBalance = 62.44
double ledgerBalance = 89.75
String currencyCd = "USD"
String id = "123"
)
If the default configuration is acceptable, then this is all you need to do. However, Jestr accepts an optional properties file that lets the user define specific stringifiers for individual classes, class hierarchies, packages, or package hierarchies, as well as to declare custom stringifiers and other objects for unique circumstances.
toString() method of a class to return a listing of the class' attributes so that they
may be logged.
However, suppose your class needs to be integrated into a larger enterprise
application that may define its own logging standards. In this case your hand-coded
toString() method will likely not conform to those standards. It is preferable to
defer the determination of logging format to the developers, and ultimately to the administrators, of
this larger application. Jestr supports this approach by making it possible to strategize the stringification
procedure so that different stringifiers can be selected at runtime based on the particular needs of
the application and circumstances at hand.
This deferral of selection of a stringification format can be done for any classes, even those that were never designed to work with
Jestr, and for which source may or may not be available. If you log such objects using "Jestr.str(x)"
instead of "x.toString()", then the current configuration will dictate whether the legacy
toString() should be called, or the class' attributes are to be listed individually, or that perhaps some
other disposition should be chosen.
| Name | Required | Default | Description |
|---|---|---|---|
jestr.configuration |
No | "jestr.properties", first in the current directory and then in the CLASSPATH |
Explicitly defines the path to the Jestr configuration file. If this file is unreadable, Jestr will log a warning and continue with the default configuration. |
jestr.configuration.reread.interval |
No | 5000 | Defines the interval in milliseconds at which the configuration file will be examined to see if its modification timestamp has changed; if the timestamp has changed, Jestr will reread it. To disable rereading of the configuration file, set this to 0. |
The following tables list all the properties that may appear in the Jestr configuration file. Note Jestr only considers properties starting with
"jestr." and ignores all others.
| Property Syntax | Required | Applies to | Description | Examples |
|---|---|---|---|---|
jestr.stringifier.name=(className|clone-of-sourceName) |
Yes | All stringifiers | Declares a stringifier. If a className is given, this class' no-arg constructor is invoked, while if sourceName is
given, the named stringifier is cloned. In either case the new stringifier is called name, and may be referenced by
this name in other directives. A library of builtin stringifiers is included with Jestr, and can be referenced
by either class or name; or you can write your own custom stringifiers. All stringifiers must implement jestr.Stringifier.
|
Example 3, Example 4, Example 5 |
jestr.stringifier.name.priority=priority |
No | All stringifiers | Sets the priority of stringifier
name to priority. The priority can be an integer from Integer.MIN_VALUE to Integer.MAX_VALUE.
Lower priority stringifiers are given preference to higher priority ones. If omitted, the priority defaults to zero. |
None |
jestr.stringifier.name.predicates=predicateName{,predicateName}* |
No | All stringifiers |
Sets stringifier name to use the given list of predicates.
For each predicateName listed, a predicate should be registered with this name, either as a builtin or via the
"jestr.predicate" directive, or
Jestr will emit a warning and ignore the predicate reference. At runtime the predicates will be evaluated in the order listed, and a
logical OR performed among their values, such that the associated stringifier will be selected if and only if at least one of the predicates
evaluates to true.
|
Example 5 |
jestr.stringifier.name.childFilter=childFilterName |
No | All stringifiers |
Sets stringifier
name to use Child Filter childFilterName. A Child Filter with this name should be registered via a
"jestr.childFilter" directive or Jestr will emit a warning and ignore this directive.
|
Example 4 |
jestr.stringifier.name.maxDepth=maxDepth |
No | All stringifiers | Sets the depth limit of stringifier name to maxDepth. The listing of the object graph will go no further than this depth. If omitted, no depth limit is imposed, though the stringification will never infinitely recurse because cycles in the object graph are automatically detected and result in limiting the depth at the point where the cycle is detected. | None |
jestr.stringifier.name.classDeclaringConstants=className |
No | enum |
Defines the name of the class
that declares constants assigning mnemonic codes to the values of an enumerated type. The "enum" stringifier will look for fields that
are declared static and final, and will compare their values to the value of the enumerated object it is stringifying. If no
match can be found, enum will substitute the string "<<unmapped>>" for the mnemonic.
|
Example 3 |
jestr.stringifier.name.constants=constant=value{,constant=value}* |
No | enum |
Explicitly defines the name/value pairs to use for mapping of an enumerated type's value to its corresponding constant name.
This property overrides the "classDeclaringConstants" property if both are present.
|
Example 3 |
jestr.stringifier.name.format=msgFormat |
No | enum |
Specifies a java.text.MessageFormat
style format string that dictates how the enumerated type should print. Two parameters will be supplied to this format: the mnemonic at position 0, and
the value at position 1. If omitted, the format is effectively "{0} ({1})". If, when the enumerated value is printed, no matching
mnemonic can be found, enum will pass the string "<<unmapped>>" for argument {0}.
|
None |
jestr.stringifier.name.dateFormat=dateFormat |
No | date |
Specifies a
java.text.SimpleDateFormat style date format string that dictates how a java.util.Date instance will be stringified. If
omitted, java.util.Date's toString() method is called, which in turn applies a locale-specific default.
|
Example 5 |
jestr.stringifier.name.format=msgFormat |
No | stringLiteral, character, silence, boolean, integer, double, long, singleLineNull, charArray, byteArray and multiLineNull |
Specifies a
java.text.MessageFormat style format string that dictates
how the object should print. The parameter passed as "{0}" is the object to be formatted. If omitted, the default is as indicated in the
"Builtin Objects" table.
|
None |
jestr.category.categoryName=stringifierName[@priority]{,stringifierName[@priority]}* |
No | All stringifiers |
Associates the named stringifier(s) with category categoryName. This means that any
object whose full class name begins with categoryName, or any of whose ancestors' full class names begin with categoryName, will be matched
by the stringifier(s) predicate(s). A stringifier with this name should exist, either as a builtin stringifier or as a result of registration via a
"jestr.stringifier" directive, or Jestr will ignore the "jestr.category" directive and log a warning.
You can specify the priority at which the stringifier is to be registered with the "
Any stringifier you list here may have a predicate already assigned in its " |
Example 2, Example 4 |
true or false. A predicate class must implement the interface
JestrPredicate.
You can write your own predicates of arbitrary complexity, but in most cases you will find the standard
predicate "standard" is all you need in the vast majority of cases.
| Property Syntax | Required | Applies to | Description |
|---|---|---|---|
jestr.predicate.name=(className|clone-of-sourcePredicateName) |
Yes | All predicates |
Declares a predicate. If a className is given, this class' no-arg constructor is invoked, while if sourcePredicateName is given,
the named predicate is cloned. In either case the new predicate is called name and may be referenced by this name
elsewhere. A standard predicate is included with Jestr, or you can write your own custom predicates. The predicate "standard", whose class
is "jestr.core.DefaultStandardPredicate" provides reasonable default behavior and can be used in most cases.
|
jestr.predicate.name.name=objectName |
No | standard |
Specifies that the object's "name" must exactly match objectName.
If omitted, then the |
jestr.predicate.name.nameIncludes=pattern{,pattern}* |
No | standard |
Defines a set of one or more Perl 5 regular expressions, at least one of
which the object's name must match in order to satisfy the predicate. If omitted, then the nameIncludes portion of the predicate is inactive and plays no
part in determining the predicate's final result.
|
jestr.predicate.name.nameExcludes=pattern{,pattern}* |
No | standard |
Defines a set of one or more Perl 5 regular expressions,
none of which the object's name can match if the predicate is to be satisfied.
If omitted, then the nameExcludes portion of the predicate is inactive and plays no part in determining the predicate's final result.
|
jestr.predicate.name.classes=classname{,classname}* |
No | standard |
Defines a set of one or more classes or interfaces, at least one of which an object must extend or implement in order to satisfy the predicate.
If omitted, then the classes portion of the predicate is inactive and plays no part in determining the predicate's final result.
|
jestr.predicate.name.parentClasses=className{,className}* |
No | standard |
Defines a set of one or more classes or interfaces, at least one of which an object's "parent" must extend or implement in order to satisfy the predicate.
An object's parent is the object that aggregates it, either as a field or as an element in a collection.
If omitted, then the parentClasses portion of the predicate is inactive and plays no part in determining the predicate's final result.
|
jestr.predicate.name.isRoot=isRoot |
No | standard |
Specifies that the object must either have a parent (if isRoot is "false") or not (if isRoot is "true") in order
to satisfy the predicate. If omitted, then the isRoot portion of the predicate is inactive and plays no part in determining the
predicate's final result.
|
NOTES:
standard" predicate performs an implicit logical AND on the predicate values implied by each of the above-listed properties.
Each such predicate must test true for the aggregate result to be true; if any test evaluates
false, then the predicate's final value will be false.
Map, the name is the key
under which the object is mapped; if the parent is a List or array, the name is the object's position as an integer ranging from 0 to the size of the
List or array minus one; if the parent is a non-List Collection, the name is the object's position in the ordering implied by the
Collection's default iterator as returned by the iterator() method; if the parent is a non-Collection, non-Map, non-array,
the name is the name of the field via which the parent holds a reference to the object.
regex", whose class is
"jestr.core.DefaultRegexChildFilter" provides Perl 5 regular expression filtering
with name substitution.
| Property Syntax | Required | Applies to | Description | Examples |
|---|---|---|---|---|
jestr.childFilter.childFilterName=(className|clone-of-sourceChildFilterName) |
Yes | All Child Filters |
Declares a Child Filter. If a className is given, this class' no-arg constructor is
invoked, while if sourceChildFilterName is given, the named Child Filter is cloned. In either case the new Child Filter is called
childFilterName and may be referenced by this name elsewhere.
All child filters must implement the interface
jestr.ChildFilter.
|
Example 4 |
jestr.childFilter.childFilterName.substitutions=pattern=replacement{,pattern=replacement}* |
No |
regex
|
Defines a list of substitutions to perform on the name of each child. Each substitution consists of a Perl 5 regular expression coupled with a Perl 5 substitition. Substitutions will be applied in the order listed. | Example 4 |
jestr.childFilter.childFilterName.nameExcludes=pattern{,pattern}* |
No |
regex
|
Defines a set of one or more Perl 5 regular expressions,
such that if the child's name matches any of these expressions, it will be excluded from the stringification processing.
Note that processing of "nameExcludes" is done after processing of "substitutions", so the child names
considered for exclusion are the names after all substitutions have been processed.
|
Example 4 |
jestr.conf.props.Initializer and declare a public no-arg
constructor. Initializers are registered via the following properties:
| Property Syntax | Description |
|---|---|
jestr.preInitializers=className{,className}* |
Defines a list of one or more initializer classes.
Before any properties have been processed, the framework will instantiate each using
its no-arg constructor and then call Initializer.preInitialize().
Initializers are processed in the order listed.
|
jestr.postInitializers=className{,className}* |
Defines a list of one or more initializer classes.
After all properties have been processed, the framework will instantiate each class using
its no-arg constructor and then call Initializer.postInitialize().
Initializers are processed in the order listed.
|
| Type | Name | Aliases | Class | Description |
|---|---|---|---|---|
| Stringifier | default |
None | jestr.core.DefaultStringifier |
A "blank" stringifier that you can clone and add attributes to. Provides only empty stringification in its own right. |
| Stringifier | enum |
None | jestr.core.EnumStringifier |
Formats values of enumerated types so that they show as their corresponding names. |
| Stringifier | singleLineNull |
null |
jestr.singleLine.SingleLineNullObjectStringifier |
Stringifies object references that are null (i.e., don't reference anything) in the single-line format. The default format
is "<<null>>" but you can change this via the "format" property. |
| Stringifier | multiLineNull |
None | jestr.multiLine.MultiLineNullObjectStringifier |
Stringifies object references that are null (i.e., don't reference anything) in the multi-line format. The default format
is "null" but you can change this via the "format" property. |
| Stringifier | xmlNull |
null |
jestr.xml.XMLNullObjectStringifier |
Stringifies object references that are null (i.e., don't reference anything) in the xml format. The default format
is "<<null>>" but you can change this via the "format" property. |
| Stringifier | character |
char |
jestr.core.CharacterStringifier |
Formats character literals. The default format is "''{0}''" but you can change this via the "format" property. |
| Stringifier | boolean |
None | jestr.core.BooleanStringifier |
Formats booleans. The default format is "{0}" but you can change this via the "format" property. |
| Stringifier | integer |
int |
jestr.core.IntegerStringifier |
Formats integers. The default format is "{0}", but with special logic for Integer.MIN_VALUE and Integer.MAX_VALUE so that these print as these constants instead of the actual numbers. You can change this behavior via the "format" property. |
| Stringifier | long |
None | jestr.core.LongStringifier |
Formats longs. The default format is "{0}", but with special logic for Long.MIN_VALUE and
Long.MAX_VALUE so that these print as these constants instead of the actual numbers. You can change this behavior via the
"format" property. |
| Stringifier | double |
None | jestr.core.DoubleStringifier |
Formats doubles. The default format is "{0}", but with special logic for Double.MIN_VALUE and
Double.MAX_VALUE so that these print as these constants instead of the actual numbers. You can change this behavior via the
"format" property. |
| Stringifier | stringLiteral |
string |
jestr.core.StringLiteralStringifier |
Formats string literals. The default format is ""{0}"" but you can change this via the "format" property. |
| Stringifier | date |
None | jestr.core.DateStringifier |
Formats java.util.Date instances according to a date format you can specify. |
| Stringifier | cycle |
None | jestr.core.DefaultCycleStringifier |
Generates a description of a cyclic reference in the object graph. These references cannot actually be followed, but this stringifier,
or any stringifier implementing the special tagging interface jestr.CycleStringifier,
is called upon to print an indication that a cycle was encountered. The default
implementation prints the string "<<cycle>>".
|
| Stringifier | byteArray |
None | jestr.core.ByteArrayStringifier |
Stringifies a byte[]. By default the first 10 bytes in the array are listed in decimal form separated by commas, but you can change this via
the "format" property. |
| Stringifier | charArray |
None | jestr.core.CharArrayStringifier |
Stringifies a char[]. The default format prints char arrays just like strings, but you can change this via the
"format" property, which is invoked with a java.lang.String equivalent of the
char array as argument {0}.
|
| Stringifier | silence |
None | jestr.core.SilenceStringifier |
Omits stringification of any matching object. The default format is "<<omitted>>", but you can
change this via the "format" property.
|
| Stringifier | tsDefault |
None | jestr.core.TSDefaultStringifier |
Defines the default approach to choosing between a class' builtin toString() method and Jestr framework stringification.
This default dictates that toString() should be called if and only if it is overridden by the class itself, or by any
superclass besides java.lang.Object. |
| Stringifier | tsNotPreferred |
None | jestr.core.TSNotPreferredStringifier |
Causes any matching object to be stringified without using its builtin toString() method even if one exists. |
| Stringifier | tsPreferred |
None | jestr.core.TSPreferredStringifier |
Causes any matching object to be stringified using its builtin toString() method. |
| Stringifier | nonCollectionSingleLine |
singleLine |
jestr.singleLine.noncollection.Noncollection- |
Causes any matching object to be stringified by listing its fields all on one line, separated by '|' characters, in a manner suitable for
input to text processing tools. Intended to be used for non-collections. |
| Stringifier | collectionSingleLine |
None | jestr.singleLine.collection.Collection- |
Causes any matching collection to be stringified by listing its elements all on one line, separated by '|' characters, in a manner suitable
for input to text processing tools. Intended to be used for arrays and objects that implement Collection or Map. If
used for other objects, fields will be ignored. |
| Stringifier | nonCollectionXML |
xml |
jestr.xml.noncollection.Noncollection- |
Causes any matching object to be stringified to XML format. Intended to be used for non-collections. |
| Stringifier | collectionXML |
None | jestr.xml.collection.Collection- |
Causes any matching collection to be stringified to XML format. Intended to be used for arrays and objects that implement Collection or Map. If
used for other objects, fields will be ignored. |
| Stringifier | nonCollectionMultiLine |
multiLine |
jestr.multiLine.noncollection.Noncollection- |
Causes any matching object to be stringified by listing its fields vertically similarly to a Java program listing. Multiline is the default stringification format. Intended to be used for non-collections. |
| Stringifier | collectionMultiLine |
None | jestr.multiLine.collection.Collection- |
Causes any matching collection to be stringified by listing its elements vertically similarly to a Java program listing. Multiline is the
default stringification format. Intended to be used for arrays and objects that implement Collection or Map. If
used for other objects, fields will be ignored. |
| Child Filter | regex |
default |
jestr.core.DefaultRegexChildFilter |
Supports filtering based on Perl 5 regular expressions. |
| JestrPredicate | standard |
default |
jestr.core.DefaultStandardPredicate |
General-purpose predicate; see "standard" predicate above for information on properties supported. |
| JestrPredicate | isCollection |
None | jestr.core.IsCollectionPredicate |
Tests whether the object is a Collection, Map or array. |
| JestrPredicate | isNonCollection |
None | jestr.core.IsNonCollectionPredicate |
Evaluates to the opposite of "isCollection". |
jestr.examples". You will also find a shell script in the
root directory of the distribution for running each example.
Follow these links for example details:
Example 1 - Default stringification.
Example 2 - Overriding an existing toString() method.
Example 3 - Enumerated types.
Example 4 - Child filtering.
Example 5 - "standard" predicate.
Example 6 - Initializers.
jestr-1.1.jar file, included with the distribution, to your CLASSPATH. You will also need all the jars that Jestr
uses in your CLASSPATH. Jestr depends heavily on the Jakarta components, specifically
the following:
jars directory.
You will also need any logger implementation compatible with Commons Logging. Log4J is the most commonly used such logger, and can be downloaded from the
Log4J site. A recent copy is also included in the jars directory.
Jestr is compatible with Java 1.4.2 or higher.
Javadoc's are available online here,
and are included in the docs/api directory under the root of the distribution.
ant" in the root of the source distribution. This will build the binary distribution complete with Javadoc's and place it in the dist directory.
|
||||||||||
| PREV NEXT | FRAMES NO FRAMES | |||||||||
